Voltage: 48V

Battery Capacity: 13Ah - 31.5Ah

Battery Type: Lithium Ion (Li-Ion), Rack

Charging Time: 5-10 hours

Feature
1, E-bike battery cell: Made of Lithium Li-on 2600mAh, 2900mAh, 3200mAh and Samsung 35E battery Cell.

2, E-bike battery life: For Li-on 2600mAh, 2900mAh, 3200mAh battery, Can charge and discharge over 1500 times, for Samsung 35E battery cell, can charge and discharge over 2000 times.

3, Size: 48V23.4Ah 2600mAh, 48V26.1Ah 2900mAh & 48V31.5Ah Samsung 35E, the battery case size is 150 x 428 x 85mm; for the rest of battery, the battery size is 150 x 388 x 85mm

4, Motor work with: 48V13Ah-15.6AH battery work with 1000w motor. 48V17.5AH-20.3Ah battery work with 1500W motor; 48V21-31.5Ah battery can work with 2000w motor;

5, Rack type. Install it on the rear rack of the bike.

Specification
1, Nominal Capacity(AH): 13AH/15.6AH/20.8AH/23.4Ah(Lithium Li-on 2600mAH Cell); 26.1AH(Lithium Li-on 2900MAH Cell); 28.8AH(3200MAH Li-on battery cell); 17.5AH/21AH/31.5AH(Samsung 35E);
2, Nominal voltage(V): 48V
3, Battery internal resistance（mΩ ）: 105
4, Cell Combination: 5x13/6x14/8x13/9x13/10X13
5, End-off voltage(V): 12
6, Charging cut-off voltage（V): 54.6
7, Rated charging current Amperage of BMS (A): 10
8, Maximum Instantaneous discharging current Amperage of BMS (A): 80 or 100
9, Maximum continuous discharging current Amperage of BMS(A）: 40 or 50
10, Battery Cell: Lithium Li-on 2600mAh, Lithium Li-on 2900mAh Li-on, 3200mAh Li-on battery cell and Samsung 35E battery cell
11, 3C discharge for 2600mAh, 2900mAh and 3200mAh, 10C discharge for Samsung 35E battery
12, Max discharging Current Amperage(A): 10
13, Charging and discharging time: more than 1000 times for 2600mAh, 2900mAh and 3200mAh; more than 2000 times for Samsung 35E.
14, Charging Type（CC-CV）: cc/cv
15, Cut-off charging voltage（V）: 54.6
16, Charge temperature range ssd: 0-50℃
17, Discharge temperature range: -20–50℃

Battery and 3A Charger
